Why Conventional Engineering Plastics Fail at mmWave Frequencies

Co

ector housings for 5G base stations, automotive radar, and high-speed test equipment must maintain dimensional stability and low dielectric loss at frequencies above 6 GHz. Standard PA66, PBT, and ABS absorb moisture, warp during lead-free reflow, and exhibit dielectric constants that drift with humidity. These variations shift impedance, increase insertion loss, and degrade signal integrity. That is why designers turn to LCP (liquid crystal polymer) and PPS (polyphenylene sulfide) modified plastics.

LCP Properties and Molding Considerations

LCP is highly anisotropic due to its rigid-rod molecular chains. In the flow direction it offers exceptional strength and a low, stable dielectric constant (Dk ≈ 2.9–3.1, Df ≈ 0.002–0.004 at 10 GHz). Its moisture absorption is negligible (<0.04 %), and it withstands 260 °C lead-free reflow without blistering.

Challenges include:

  • Weld-line weakness: Knit lines can be 30 %–50 % weaker than the bulk, so gate placement is critical.
  • Anisotropic shrinkage: Parts must be oriented consistently in the mold to hold tight tolerances.
  • Higher material cost: LCP resin is typically 2–4× the price of PBT.

PPS Properties and Cost Position

PPS provides excellent chemical resistance, very low moisture uptake (<0.05 %), and good dimensional stability up to 240 °C. Unfilled PPS has Dk ≈ 3.0–3.4 and Df ≈ 0.002 at 1 GHz, though Df rises somewhat above 10 GHz. Glass-fiber-reinforced PPS (30 %–40 % GF) is common for co

ector housings that need structural rigidity and cost control.

PPS is generally easier to mold than LCP, with more isotropic shrinkage and fewer weld-line issues. It is the default choice for high-volume automotive and industrial RF co

ectors.

Comparative Performance: Df, Dk, CTE, Moisture, and Solder Reflow

Property LCP PPS-GF40 Relevance
Dk at 10 GHz 2.9–3.1 3.2–3.6 Lower Dk reduces capacitive coupling
Df at 10 GHz 0.002–0.004 0.003–0.007 Lower Df minimizes insertion loss
Water absorption <0.04 % <0.05 % Stability in humid climates
HDT / reflow peak >300 °C 240–260 °C Lead-free compatibility
CTE (flow direction) 5–16 ppm/°C 20–30 ppm/°C Match to metal inserts and PCB

Selection Decision Matrix by Application

  • 5G mmWave test co

    ectors and ante

    a interfaces: LCP wins on Df and dimensional precision.

  • Automotive radar and outdoor base stations: PPS-GF40 offers the best balance of cost, chemical resistance, and reflow stability.
  • High-density board-to-board co

    ectors: LCP enables thi

    er walls and tighter pitch.

  • Power-hybrid RF co

    ectors: PPS handles higher mechanical loads and insert forces.

Both materials benefit from molded-in metal inserts and laser-direct-structuring (LDS) additives when ante

a traces or grounding features are integrated into the housing. Choosing between LCP and PPS comes down to frequency, tolerance budget, volume, and cost.
